DIP Switch Setting for SEC-2440A

S1 S2 Float Boost Battery Type Charging Stages

/ Application

Stand-alone charging

OFF * ON * 27 V * 28.8 V * Flooded / AGM * 3 Stages (Stages 1, 2, 3)

ON OFF 27 V 28.0 V Gel Cell 3 Stages (Stages 1, 2, 3)

Charging loaded battery

Charging two banks and the batteries in the two banks are in dissimilar discharged

condition

OFF OFF 27 V 27.0 V Loaded Battery 2 Stages (Stages 1, 3)

(can be Flooded

/ AGM / Gel Cell)

* Factory preset in this position

CAUTION!

Please ensure that position S1- ON and

S2 – ON is never selected

SELECTING THE TIME FOR STAGE 2 - CONSTANT OVERCHARGE VOLTAGE,

TIMED ABSORPTION / BOOST CHARGE MODE (“Uo” PHASE)

Stage 2 - Constant Overcharge Voltage, Timed Absorption / Boost Charge Mode (“Uo”

Phase) is controlled by an internal timer circuit. Time of 4 hours or 8 hours can be selected

with the help of a pair of switches S3 & S4 of the set of 4 DIP Switches (5). Select the times

as follows:

Time DIP Switch S3 DIP Switch S4 Type of Battery

4 hours* Off* On* Flooded / wet cell

8 hours On Off Gel Cell & AGM

Disable Off Off -

* Factory preset in this position

CAUTION!

Please ensure that position S3- ON and

S4 – ON is never selected
